CNC PRECISION THREAD GRINDER
| CNC35-TDG400 TECHNICAL DATA | |
|---|---|
| MAIN DIMENSIONS | |
| SWING DIAMETER OVER THE TABLE | 306 mm |
| MAX. WORKPIECE LENGTH | 200 mm |
| MAX. WORKPIECE WEIGHT | 40 kg |
| MAX. WORKPIECE OUTSIDE DIAMETER RANGE | Ø 300 mm |
| THREAD GRINDING LENGTH | max. 200 mm |
| EXTERNAL THREAD DIAMETER GRINDING RANGE | max. Ø 200 mm |
| CENTER HEIGHT | 153 mm |
| MACHINE DIMENSION (L X W X H) | 2000 x 2220 x 2278 mm |
| TOTAL WEIGHT | 3300 kg |
| LONGITUDINAL AXIS X | |
| MAX. TRAVEL | 270 mm |
| SPEED | 5000 mm/min |
| RESOLUTION | 0.001 mm |
| TRANSVERSE AXIS Z | |
| MAX. TRAVEL | 350 mm |
| SPEED | 5000 mm/min |
| RESOLUTION | 0.001 mm |
| GRINDING WHEEL | |
| GRINDING WHEEL (OD x WIDTH x ID) | dia. 405 x 20 x dia. 152.4 mm, dia. 405 x 20 x dia. 203.2 mm |
| SPINDLE SPEED | 2100 rpm |
| MAX. WHEEL SURFACE SPEED | 45 m/sec |
| HELIX ANGLE | -5~+19 deg |
| DRIVING POWER | 10 hp |
| DRIVING POWER | |
| AXIS X | 1.8 kw |
| AXIS Z | 1.8 kw |
| HYDRAULIC PUMP | 1 hp |
| WHEEL LUBRICATION PUMP MOTOR | 1 hp |
| WORKHEAD SPINDLE | |
| RPM RANGE | 0 – 75 rpm |
| INNER HOLE TAPER | MT.4 |
| THROUGH SPINDLE HOLE DIAMETER | Ø 18 |
| WORK SPINDLE | 1.8 kw |
| TAILSTOCK | |
| FITTING TAPER | MT.4 |
| BARREL STROKE | 40 mm |
| HYDRAULIC TAILSTOCK (optional) | - |
| CONTROLLER | |
| Computer：FANUC 0i – TF PLUS | Software：JIMATIC – F9000T |
| Computer：SYNTEC 22MA | Software：JIMATIC – S9000 |
